Hinge to Weld 3 Wings Removable Pin
Galvanised pin and washer
Product Details
Welding hinge to be welded on metal swinging doors. To be used in order to open very heavy metal gates, openings or door leaves.
Natural steel shell with a galvanised steel pin.
Code | Amm | Ømm | Bmm | Dmm | Pieces |
---|---|---|---|---|---|
402080 | 80 | 12 | 16.5 | 8 | 24 |
402100 | 100 | 13.5 | 18 | 8.5 | 24 |
402120 | 120 | 15 | 19.5 | 10 | 24 |
402140 | 140 | 16.5 | 22 | 10.5 | 24 |
402170 | 170 | 17.5 | 23.5 | 12 | 12 |
402200 | 200 | 20 | 27 | 14 | 12 |
