ADG Pro Top Fix is a Galvanized Heavy Duty Hanging System for PVC Strip Curtains.

Standard stock item we can dispatch to-day.

We can also manufacture your strip curtain into a kit form ready to fit with the hinge and counterplates already attached

Professional choice for easy installation of PVC strip curtains Pre Punched slotted fixing channel for vertical fixing, side wall mounting or use with our optional sliding rail no drilling of the top fix is necessary for most installs.

Supplied with a cover strips to enhance appearance and keep the strips attached to the rail. Suitable for 200mm 300mm 400mm wide strips. Hinge and Counter plate allow the strips to move for easier passage. Strips can be easily added or removed or replaced

Product Details
Top fix Pro PVC strip curtain Hook on mounting rail made from high quality galvanised steel.

Suitable for external or internal divides

PVC strip doors have a variety of uses example such as Thermal Barriers in Warehouses Cold Rooms Clean rooms COVID 19 Screening Spray Booths Pest control stopping vermin such as birds and bugs entering a warehouse but also allowing the door to be open.

Warehouse Work Area Divides

Code SB2000 Support Bracket 2000mm

Code SB1200 Support Bracket 1200mm

Code SB800 Support Bracket 800mm

Code SB600 Support Bracket 600mm

Code SC1200 Snap Cover 1200mm

Code SC800 Snap Cover 800mm

H200 Hinge 200mm

C200 Counter plate 200mm

H300 Hinge 300mm

C300 Counter plate 300mm

400mm strips use 2 H200 and 2 C200.

Specifications
ADG PVC support brackets has installation options:

Fix under the lintel

Fix to the wall

Use some of our Sliding track and rollers option to allow a strip curtain to be moved.

The Support Bracket has a galvanized finish with a large quantity of slotted holes ensuring straight forward and trouble-free installation.

Hinges and Counter Plates are attached to the strips by strong M8 bolts.

A special support bracket Cover Plate ensures a sleek finish and helps prevent any strips from falling off.
